Number of seats in the cabin |
3 |
|
Overall dimensions at transport mode: |
|
|
- length |
10700 mm |
|
- width |
4160 mm |
|
- height |
4000 mm |
|
Gross weight (including the excavator) |
26000 kg |
|
Track |
2900 mm |
|
Track width |
1260 mm |
|
Ground pressure |
0,2 kg/cm2 |
|
Max. speed |
18 km/h |
|
Max. speed afloat |
5 km/h |
|
Chassis engine |
YAMZ-238B (EURO-0) |
|
Max. engine power |
221 kw |
|
Engine |
D-245.9, diesel |
|
Excavator hydraulic pump volume |
400 L |
|
Excavator fuel tank volume |
210 L |
|
Technical performance, no less than |
160 m³/h |
|
Digging ranges |
|
|
Max. digging depth |
4300 mm |
|
Max. digging reach |
10500 mm |
|
Max. loading height |
3600 mm |
|
Telescopic boom stroke |
4150 mm |
|
Max. telescopic boom elevation angle |
30° |
|
Max. telescopic boom dropping angle |
60° |
|
Bucket rotation angle: |
|
|
- narrow axis of rotation |
152° |
|
- axial axis of rotation |
360° |
|
Estimated bucket capacity |
0,8m3 ± 5% |
At least 10 types of attachments can be used additionally. You can see the full list of attachments on the Attachments page.
